The Seco Walleye Prism System for Monitoring and Mining 62mm is a heavy-duty surveying prism engineered for long-range monitoring, mining, geotechnical observation, and construction applications.Â
Designed to house a full-size 62 mm prism, the system delivers reliable signal reflection and precise measurements in demanding outdoor environments. Its rugged mounting bracket, integrated rain hood, and dual-axis adjustment mechanism make it suitable for permanent and semi-permanent monitoring installations.
The SECO Walleyeâ„¢ Prism System is designed for professionals who require dependable prism performance in challenging environments. Whether installed on mining infrastructure, retaining walls, bridges, tunnels, or construction sites, this monitoring prism system provides stable positioning and consistent measurement accuracy over extended periods.
The robust design supports accurate deformation monitoring, structural inspection, and high-precision surveying tasks where reliability is critical.
Key Features of the SECO Walleye Prism System
Large 62 mm Prism for Extended Measurement Range
The integrated holder accommodates a full-size 62 mm prism, providing strong signal return and enhanced visibility for total stations operating over long distances.
Adjustable −40 mm Prism Constant
The prism system features a standard −40 mm prism offset with an adjustment tolerance of ±2 mm, allowing surveyors to configure the setup according to project requirements.
Dual-Axis Alignment Mechanism
The pivoting mount enables adjustment in two axes, making it easier to align the prism accurately on uneven surfaces, monitoring stations, and complex installations.
Integrated Rain Hood Protection
A built-in protective hood helps shield the prism from rain, dust, and debris, reducing maintenance requirements and supporting dependable field performance.
Rugged Mounting Bracket for Permanent Installations
The heavy-duty L-bracket incorporates multiple mounting points and stainless-steel locking components, ensuring stability in harsh construction and mining environments.
Standard Survey Compatibility
The included 5/8″ × 11 adapter provides compatibility with common survey poles, mounting systems, and monitoring equipment.
Applications and Use Cases
The Seco Walleye 62 mm Prism System is suitable for:
- Mining and quarry monitoring
- Structural deformation monitoring
- Tunnel and underground construction projects
- Bridge and dam inspection
- Rail and transportation infrastructure surveys
- Building settlement observation
- Geotechnical monitoring systems
- Long-term construction control networks
- Industrial site monitoring
Benefits
- Delivers reliable long-range prism performance.
- Supports accurate monitoring and surveying workflows.
- Provides flexible positioning through dual-axis adjustment.
- Helps maintain measurement quality in harsh weather conditions.
- Offers durable construction for permanent outdoor installations.
- Works with standard survey poles and M20 prism canisters.
- Simplifies installation on walls, structures, and fixed monitoring points.
Technical Specifications
| Specification | Details |
| Brand | SECO |
| Product Name | Walleye Prism System |
| Product Type | Monitoring and Mining Prism |
| Prism Diameter | 62 mm |
| Prism Constant | −40 mm |
| Adjustment Range | ±2 mm |
| Coating Type | None |
| Holder Connection | 5 × Screw Holes |
| Mount Type | Heavy-Duty L-Bracket |
| Adapter Thread | 5/8″ × 11 |
| Prism Compatibility | M20 Screw-In Prism Canisters |
| Adjustment Axes | Dual-Axis Pivot |
| Protective Feature | Integrated Rain Hood |
Why Choose the SECO Walleye Monitoring Prism System?
Engineered for Harsh Environments
Mining sites, construction projects, and infrastructure monitoring applications demand durable equipment. The Walleye Prism System is built to withstand challenging outdoor conditions while maintaining measurement consistency.
Optimized for Monitoring Accuracy
The combination of a large 62 mm prism, adjustable prism constant, and stable mounting hardware helps survey professionals achieve precise results in long-term monitoring projects.
Flexible Installation Options
The large mounting base and multiple attachment points enable installation on concrete, steel structures, retaining walls, and custom monitoring assemblies.
Frequently Asked Questions
What is the primary use of the Seco Walleye Prism System?
The Seco Walleye Prism System is primarily used for mining, structural monitoring, deformation surveys, tunnel projects, and long-range total station measurements.
What prism size does this system support?
This system is designed to accommodate a full-size 62 mm prism for improved signal reflection and long-distance measurement performance.
What is the prism constant of the Walleye Prism System?
The prism constant is −40 mm, with an adjustment tolerance of ±2 mm.
Can the prism system be installed permanently outdoors?
Yes. The heavy-duty bracket, stainless-steel hardware, and integrated rain hood make it suitable for long-term outdoor installations.
Is the system compatible with standard survey equipment?
Yes. The included 5/8″ × 11 adapter allows compatibility with standard survey poles and mounting systems.
Does the Walleye Prism System support interchangeable prisms?
Yes. The system is compatible with M20 screw-in prism canisters, allowing different prism configurations when needed.
